Avaya Room Camera RC100

Avaya Room Camera RC100 is a flexible and high-end solution covering a broad spectrum of room sizes and use cases. It is an Ultra HD 60fps camera, with 24x Full HD Zoom. Used as an HDMI camera, it can support up to 2160p60 resolution, and 1080p60 when used with Avaya XT Series. It also supports USB connectivity and IP SRTP connectivity.

Avaya Room Camera RC100 is a flexible and high-end solution covering a broad spectrum of room sizes and use cases.

Avaya Room Camera RC100 is well-suited for a wide range of scenarios and use cases — thanks to its high-end features and connectivity. It is an Ultra HD 60fps camera, with 24x Full HD Zoom (12x Ultra HD Optical Zoom). Used as an HDMI camera, it can support up to 2160p60 resolution, and 1080p60 when used with Avaya XT Series. USB connectivity allows easy interoperability with laptops — up to 2160p30 resolution with devices supporting such resolution (both Windows and macOS). It also allows easy connectivity with Avaya XT Series (up to 1080p30) and with Avaya CU360 (up to 720p30). IP connectivity makes Avaya Room Camera RC100 suitable for surveillance and extends the video range of Avaya CU360 (up to 1080p30 resolution).

Specifications

Camera Model –                                      Avaya Room Camera RC100 24x at 1080p60/12x at 2160p60
Image device-                                          1/2.8 Inch, CMOS, effective pixels: 8.46 MP
Video Formats supported-                   2160p60/50/30/25, 1080p60/50/30/25, 720p60/50/30/25
Video Formats with Avaya XT Series-Using HDMI: 1080p60/50/30/25, 720p60/50/30/25
Using USB: 1080p30/25, 720p60/50/30/25
Video Formats with Avaya CU360-    Using IP: 1080p30/25, 720p60/50/30/25
Using USB: 720p30/25
Video signal-                                            HDMI (up to 4Kp60),
H.264 and MJPEG (up to 4Kp30) on USB,
RTSP H.264 AVC (up to 4Kp30) on IP
Focal Length-                                           f= 3.4mm ~40.3mm, F 1.8 ~ 3.6
Min object distance (wide)-                  250 (Wide) ~1000 (Tele) mm
Min illumination-                                   0.5 lux at F 1.8, AGC ON
HFoV-                                                       81°
VFoV –                                                       50°
Full HD Zoom (at 1080p)-                   24x
Ultra HD Zoom (optical at 2160p)-    12x
Digital Zoom-                                           8x
Pan Range-                                              +/- 130°
Tilt Range-                                              -30° ~+90°
Camera Control-                                    Serial Visca in-out, UVC over USB, IP Webcam Protocol
Ceiling Mount-                                       Supported

Weight –                                                  1.69kg (3.72 lbs.)
Dimensions w/h/d-                             250mmx165mmx135mm (9.84×6.49×5.31”)
Current consumption (max)-            2.5A (power supply 12v at 2,5A)
Avaya clients supported-                   Avaya Spaces, Avaya Cloud Office (ACO), Workplace, Equinox
3rd party clients supported-            MS® Teams, MS® SfB, Skype®, Zoom®, Bluejeans®, Starleaf®, Pexip®,

Cisco Webex®,Google Hangouts®
Video configurations-                        White balance (auto/manual); Focus Mode (auto/manual); Sharpness; Backlight;
Exposure Compensation; Picture (auto/manual) and WDR level
Voltage Range-                                    12V +/-5%
IR repeater as TTL signal-               Yes
Camera Output-                                 HDMI, USB, Ethernet
Audio input-                                       Jack stereo 3,5”
Audio output-                                    USB, HDMI, Ethernet
USB control-                                      UVC/UAC, Plug and Play
Presets-                                              12 when controlled from camera’s own remote control, 122 when controlled from
Avaya XT Series or Avaya CU360
Far end camera control-                 Through Avaya XT Series or Avaya CU360 codec (H.224, H.281) or third-party App
Accessories in the box-                    Remote Control with batteries, 2.5m HDMI 2.0 cable, 4.5m USB 2                                                               cable, Power Supply Unit, wall mount, screws set, Lens cap and Documentation
Kensington Security Slot-               Kensington Security Slot available
