Viewsonic TD2230

TD2230 – 22″ Display, IPS Panel, 1920 x 1080 Resolution

The ViewSonic^® TD2230 is a 22” (21.5” viewable) Full HD multi-touch display. With a SuperClear^® IPS panel and 10-point projected capacitive touch technology, this display delivers stunning front-of-screen performance with a responsive and accurate touch experience. Featuring a 7H hardness touch screen, edge-to-edge frameless design, and up to 10 simultaneous touch points, this durable display allows users to tap, swipe, pinch, and zoom with ease – perfect for retail, education, or enterprise. An advanced ergonomic bookstand design provides a full range of motion for the desktop, and a VESA-compatible mount allows for flexible mounting options on a monitor stand or wall. Future-proof connectivity options include HDMI, DisplayPort, and USB 3.0, while VGA is also available for legacy systems. Cross compatibility with a wide range of operating systems include Windows 10, and certain Android and Linux versions. ViewSonic’s exclusive ViewMode™ feature provides intuitive presets for optimized screen performance in different applications. In addition, Flicker-Free technology and a Blue Light Filter help to minimize eye strain from extended viewing periods. Industry-leading warranty protection and legendary ViewSonic product quality makes this high performance multi-touch display a great long-term investment for all touch applications.

SUPERCLEAR ® IPS PANEL TECHNOLOGY

Enjoy accurate and vivid colors with consistent levels of brightness no matter the vantage point. With SuperClear IPS panel technology, this monitor delivers the same image quality whether you are looking at the screen from above, below, the front, or the side.

10-POINT MULTI-TOUCH

Touch screens with projected capacitive touch can recognize up to 10 points of simultaneous contact, allowing for a highly accurate and ultra-responsive touch experience. With smooth and responsive touch capabilities, this touch display is ideal for home entertainment, office work, education, and commercial use.

FRAMELESS DESIGN

This monitor features a frameless edge-to-edge screen that delivers an immersive viewing experience. With its sleek, eye-catching design, this monitor looks as good as it performs

VERSATILE CONNECTIVITY

DisplayPort, HDMI, and VGA inputs give you the freedom to connect your display to a variety of devices.

DURABLE, SCRATCH-RESISTANT SCREEN

This touch display is designed with a durable, protective glass faceplate. This provides increased scratch protection to ensure durability, as well as a consistent, high-quality touch experience in high-traffic areas such as educational settings, or other public environments where the touch display can be used as a kiosk.

MULTI-TOUCH FOR MAC OS

With the all new vTouch^TM driver, MacOS users can now access a full range of touch and gesture controls on ViewSonic® TD external touch displays connected to their Apple products.

SPECIFICATION:

DISPLAY

DISPLAY SIZE (IN.): 22

VIEWABLE AREA (IN.): 21.5

PANEL TYPE: IPS

RESOLUTION: 1920 x 1080

STATIC CONTRAST RATIO: 1,000:1

DYNAMIC CONTRAST RATIO: 50,000,000:1

LIGHT SOURCE: LED

BRIGHTNESS: 250 cd/m2

COLORS: 16.7M

RESPONSE TIME (TYPICAL GTG): 14ms

VIEWING ANGLES: 178º horizontal, 178º vertical

BACKLIGHT LIFE (HOURS): 30,000

PANEL SURFACE: Anti-glare, Hard coating 7H

COMPATIBILITY

PC RESOLUTION (MAX): Up to 1920×1080 non-interlaced

MAC® RESOLUTION (MAX): Up to 1920×1080

CONNECTOR

USB 3.0 TYPE A: 2

USB 3.0 TYPE B: 1

3.5MM AUDIO IN: 1

3.5MM AUDIO OUT: 1

HDMI IN: 1

VGA: 1

DISPLAY PORT: 1

POWER IN: DC 19V/2.37A
