CMX- IP network powered speaker DI-9723
IP Network Powered Speaker
RJ45 LAN Connectivity
20W + 20W Stereo Output
Built-in Class-D Amplifier
6.5” Woofer + 1.5” Tweeter
Crystal Clear Voice & Music Output
Mic Input + RCA Aux Input
TCP/IP Network Audio Support
Wall Mount Bracket Design
Ideal for School, Office & Hospital PA Systems
Best for Announcements & Background Music
Reliable Commercial Audio Solution
CMX DI-9723 IP Network Powered Speaker | LAN-Based Wall Mount PA Speaker for Schools, Offices & Commercial Use
The CMX DI-9723 IP Network Powered Speaker is a professional LAN-based active speaker system designed for schools, offices, hospitals, classrooms, malls, factories, and commercial public address systems across India. Built for reliable and crystal-clear audio performance, this IP network powered speaker offers seamless sound transmission over existing RJ45 Ethernet / LAN infrastructure, making it an ideal choice for modern PA and announcement systems. Powered by a 20W + 20W stereo Class-D built-in amplifier, the DI-9723 delivers clear voice announcements, balanced music playback, and distortion-free sound output for everyday communication needs. Whether used for school announcements, office paging, emergency alerts, or background music, it ensures professional sound quality in every environment.
The speaker comes with a 2-way acoustic design featuring a 6.5-inch woofer and 1.5-inch tweeter, which provides strong bass response and clear high-frequency voice output. This makes it perfect for spaces where speech clarity is important, such as classrooms, hospital corridors, offices, reception areas, and training rooms.
Frequently Asked Questions (FAQs)
1. Is this an active speaker?
A-1 Yes, it comes with a built-in stereo amplifier.
2. Does it support LAN network?
A-2 Yes, it supports RJ45 Ethernet / LAN connectivity.
3. Can it be used for school announcements?
A-3 Yes, it is perfect for school, classroom, and office PA systems.
4. Does it support microphone input?
A-4 Yes, it has a microphone input and RCA auxiliary input.
5. Is it wall mountable?
A-5 Yes, it includes a wall mount bracket.
Specification
| Brand | CMX Audio |
| Model | DI-9723 |
| Product Type | IP Network Powered Speaker |
| Speaker Type | Active + Passive Speaker Set |
| Network Input | Standard RJ45 LAN Port |
| Network Speed | 10 / 100 Mbps |
| Communication Protocol | TCP/IP, UDP, IGMP |
| Audio Format | MP3 / MP2 |
| Sampling Rate | 8KHz – 48KHz |
| Audio Mode | 16-bit Stereo CD Quality |
| Frequency Response | 20Hz – 16KHz |
| THD | ≤ 0.1% |
| S/N Ratio | > 70 dB |
| Power Output | 20W + 20W Stereo Class-D Amplifier |
| Speaker Configuration | 6.5” Woofer + 1.5” Tweeter (2-Way) |
| Aux Input | 1 × RCA Input (400mV) |
| Mic Input | Yes |
| Tone Controls | Bass / Treble / Master / Echo |
| Speaker Output | Passive Speaker Output |
| Indicators | Status + Power LED |
| Power Supply | AC 220V – 240V / 50Hz |
| Power Consumption | ≤ 40W |
| Dimensions | 260 × 140 × 188 mm |
| Weight | 6 Kg |
| Mounting Type | Wall Mount Bracket |
| Application | School, Office, Hospital, Classroom, PA System |
