CMX PA-4120 – 4 Zone Mixer Amplifier
4 Zone Independent Audio Control
4 × 120W Powerful Sound Output
USB / SD / FM / Bluetooth Support
100V, 70V & 8–16 Ohm Compatible
3 Mic Inputs + AUX Support
Clear Paging & Announcement System
Bass & Treble Sound Control
Remote Mic & Panel Support
Rack Mount / Table Top Design
Best for Hotel, Office, School & Mall
CMX PA-4120MX 4 Zone Mixer Amplifier with USB / SD / FM / Bluetooth
Upgrade your commercial sound system with the CMX Audio PA-4120MX 4 Zone Mixer Amplifier, a powerful and professional public address (PA) amplifier designed for hotels, restaurants, schools, offices, malls, showrooms, and commercial spaces across India. This advanced 4 zone mixer amplifier delivers 4 × 120W RMS output, allowing you to control audio independently in four separate zones. Whether you need different music or announcements in multiple rooms, floors, cabins, or areas, this amplifier gives you complete flexibility and crystal-clear sound performance. Built with a 4 channel power amplifier and audio matrix system, the PA-4120MX supports USB, SD card, FM radio, and Bluetooth connectivity, making it easy to play music from mobiles, laptops, pen drives, or other audio devices.
Frequently Asked Questions
1. What is a 4 zone mixer amplifier?
A-1 A 4 zone mixer amplifier allows you to control audio in four separate areas independently, such as different rooms, floors, or shop sections.
2. Can I connect Bluetooth devices?
A-2 Yes, this model supports Bluetooth connectivity for wireless music playback from smartphones and laptops.
3. Is it suitable for schools and offices?
A-3 Absolutely. It is widely used for school paging systems, office announcements, hotels, and malls.
4. Does it support microphone announcements?
A-4 Yes, it supports multiple microphone inputs and remote paging microphones.
5. Which speakers can be connected?
A-5 It supports 100V line speakers, 70V line speakers, and 8–16 ohm speakers.
Specification
| Model | PA-4120MX |
| Brand | CMX Audio |
| Product Type | 4 Zone Mixer Amplifier |
| Power Output | 4 × 120W RMS |
| Amplifier Type | Built-in 4 Channel Power Amplifier + Audio Matrix |
| Zone Output | 4 Independent Zones |
| Speaker Output | 100V / 70V / 8–16 Ohms |
| Connectivity | USB / SD Card / FM / Bluetooth |
| Microphone Inputs | 3 Mic / Line Inputs |
| AUX Input | 1 AUX Input |
| Input Connector | Balanced COMBO XLR + RCA |
| Phantom Power | +48V Supported |
| Line Output | 0.775V (0dBV) |
| Priority Function | Mute / EMC / Mic 1 Priority |
| Tone Control | Bass & Treble Control |
| Remote Paging Support | Up to 8 Remote Microphones |
| Remote Panel Support | Up to 4 Remote Control Panels |
| Signal to Noise Ratio | > 80 dB |
| THD | < 0.1% |
| Protection | Short Circuit / Overload / Clip / High Temperature |
| Cooling System | Built-in Fan Cooling |
| Installation Type | Rack Mount / Table Top |
| Power Supply | 230V AC / 50–60Hz |
| Application | Hotel, Restaurant, School, Office, Mall, Commercial PA System |
