Sonodyne XRS12ODV Passive Speaker
Rs.106,360.00 Price Excluding TAX
▷ Professional 12-Inch Outdoor Passive Speaker
▷ Powerful 300W Continuous Power Handling
▷ 600W Program Power and 1200W Peak Power Capacity
▷ High-Performance 2-Way Speaker Design
▷ 12-Inch Woofer for Deep Bass and Powerful Sound
▷ 2-Inch Compression Driver for Clear High Frequencies
▷ Built-In 70V / 100V Line Transformer
▷ Multiple Power Taps: 300W / 150W / 75W / 37.5W
▷ Supports Both 70V/100V Line and 8 Ohm Systems
▷ Wide 90° x 90° Sound Coverage Pattern
▷ High 97dB Sensitivity for Efficient Audio Performance
▷ Perfect for Stadiums, Hotels, Resorts and Schools
Sonodyne XRS12ODV 12 Inch Outdoor Passive Speaker
The Sonodyne XRS12ODV is a premium 12-inch outdoor passive speaker engineered for high-performance public address, background music, and commercial audio installations. Designed to deliver powerful sound coverage in large indoor and outdoor spaces, this professional 2-way loudspeaker combines a high-output 12-inch woofer with a 2-inch compression driver for exceptional clarity, speech intelligibility, and deep bass response.
With 300W continuous power handling, 600W program power, and 1200W peak power capacity, the XRS12ODV is ideal for demanding audio environments such as stadiums, hotels, resorts, shopping malls, educational campuses, gardens, and large outdoor venues. The built-in 70V/100V line transformer with multiple power taps allows seamless integration into distributed speaker systems, while the 8-ohm bypass mode offers compatibility with conventional amplifier installations.
Its rugged injection-moulded cabinet and IP44-rated weather-resistant construction ensure reliable operation in outdoor conditions. Multiple mounting options including U-bracket, pole mounting, and rigging points provide flexible installation for professional sound system projects across India.
Frequently Asked Questions (FAQs)
The Sonodyne XRS12ODV is designed for outdoor public address systems, commercial audio installations, background music systems, and sound reinforcement applications in large indoor and outdoor spaces.
Yes. The speaker features an IP44-rated weather-resistant enclosure that provides reliable performance in outdoor and semi-exposed environments.
Yes. The built-in transformer supports both 70V and 100V distributed audio systems with selectable power taps.
Yes. The XRS12ODV supports 8-ohm bypass operation, allowing connection to conventional low-impedance amplifiers.
The speaker is ideal for hotels, resorts, schools, stadiums, shopping malls, gardens, outdoor venues, public address systems, and commercial audio installations.
Specification
| Product Model | Sonodyne XRS12ODV |
| Product Type | 12″ Outdoor Passive Speaker |
| Speaker Configuration | 2-Way Passive Loudspeaker |
| Low Frequency Driver | 12″ Woofer |
| High Frequency Driver | 2″ Compression Driver |
| Continuous Power Handling | 300W |
| Program Power | 600W |
| Peak Power | 1200W |
| Power Taps (70V/100V Line) | 300W / 150W / 75W / 37.5W |
| Impedance | 8 Ohms (Bypass) |
| Frequency Response | 50Hz – 18kHz |
| Sensitivity | 97dB (1W/1m) |
| Maximum SPL | 127dB Peak |
| Coverage Angle | 90° x 90° |
| Transformer | Built-In 70V / 100V Line Transformer |
| Weather Protection | IP44 Rated Outdoor Design |
| Enclosure Material | Heavy-Duty Injection Moulded Cabinet |
| Mounting Options | U-Bracket, Pole Mount & 6 x M8 Rigging Points |
| Connection Type | Captive Fly Lead |
| Colour | Black |
| Dimensions (W × D × H) | 415 × 382 × 620 mm |
| Net Weight | 22 kg |
| Warranty | 5 Years |
| Applications | Hotels, Resorts, Schools, Stadiums, Shopping Malls, Gardens, Outdoor PA Systems, Commercial Audio & Background Music |
